Ramsond RDZ Series 18,000 BTU Dual‑Zone Mini Split Heat Pump, Wi‑Fi Ready, 25 FT Line Set Included

Image 1
  • Image 1
  • Image 2
  • Image 3
  • Image 4
  • Image 5
  • Image 6
Price:
Please Visit any retailer listed

Product Description

RDZ Multi‑Zone Mini Split System – Product Overview
Product Image 1

Zone Configuration

The Ramsond RDZ Series 18,000 BTU Dual‑Zone Mini Split System delivers efficient, targeted comfort for multiple rooms at once. Each zone is powered by a dedicated 9,000 BTU wall‑mount indoor unit, ideal for cooling and heating spaces up to 400 sq ft per zone — perfect for kitchens, living rooms, bedrooms, offices, and multi‑room layouts that demand reliable temperature control.

The outdoor condenser arrives fully pre‑charged with environmentally safe R410A refrigerant, engineered for quick installation and dependable performance. Every system includes a 25 ft insulated copper line set kit, allowing flexible placement of each indoor unit without additional charging or complex setup.

With advanced inverter technology, whisper‑quiet operation, and optional Wi‑Fi control, the RDZ Dual‑Zone system provides year‑round comfort, reduced energy consumption, and precise climate control across two separate rooms — all from one compact, high‑efficiency system.


Efficiency & Features

The Ramsond RDZ Multi‑Zone Wall‑Mount System is engineered for high‑performance comfort and year‑round efficiency. With inverter technology and ratings up to 24 SEER, the system automatically adjusts output to maintain precise temperatures while reducing energy consumption. Each indoor unit features advanced air filtration, multiple comfort modes, and Sleep Mode for quiet nighttime operation.

Integrated Wi‑Fi control allows full system management from any smartphone, giving users access to scheduling, mode selection, and real‑time performance monitoring. Intelligent system protections—including Intelligent Defrost and optimized refrigerant management—ensure reliable heating performance in cold‑weather conditions. The outdoor unit is built on Ramsond’s durable ODU chassis belt design, providing enhanced structural stability, vibration control, and long‑term reliability across all zones

Installation & Warranty

The RDZ Multi‑Zone system includes a 25 ft installation kit with insulated copper line sets, communication wiring, drain tubing, and all essential fittings for a streamlined setup. Ramsond’s EAZY‑INSTALL support ensures faster, cleaner installation with pre‑charged refrigerant, simplified connections, and clear routing for multi‑zone layouts.

Each system is backed by Ramsond’s industry‑leading protection: a 5‑year limited parts warranty and a 7‑year compressor warranty, providing long‑term confidence and reliable performance across every zone.




Specifications by Size
SpecificationSize 1Size 2Size 3Size 4
Model RDZ18-HP-230V RDZ28-HP-230V RDZ36-HP-230V RDZ45-HP-230V
Capacity (BTU) 18,000 28,000 36,000 45,000
Zones 2 Zones 3 Zones 4 Zones 5 Zones
Voltage 230 V 230 V 230 V 230 V
SEER Rating 19 SEER 20 SEER 22 SEER 23 SEER
Refrigerant 454B 454B 454B 454B
Included Line Set 25 FT × 2 25 FT × 3 25 FT × 4 25 FT × 5
Indoor Unit Type Wall‑Mount Wall‑Mount Wall‑Mount Wall‑Mount
Wi‑Fi Ready Yes Yes Yes Yes
Noise Level (Indoor) ≤ 30 dB ≤ 32 dB ≤ 34 dB ≤ 36 dB
Operating Modes Cool / Heat / Dry / Fan Cool / Heat / Dry / Fan Cool / Heat / Dry / Fan Cool / Heat / Dry / Fan
Warranty 5/7 Years 5/7 Years 5/7 Years 5/7 Years
Max Amp 25  30 35 40
